1. Power pre-stretcch film carriage, save 30%-50% on packing cost.
2. Highly Reduce labor cost.
3. Lower investment（USD 2000-2500.）
4. Easy to installation.
5. Fast delivery.(3days)
Size of The Loads ( Pallets)
Min load size | 500mm (L) X 500mm (W) |
Max load size | 1200mm (L) X 1200mm (W) |
Max load height | 2400mm (Option:2800mm, 3000mm) |
Max load weight | 2000kg (4400lbs) |
Machine Performance
Packing efficiency | 20-30 loads/hour |
Load height sensing by PE | YES |
Turntable soft start & stop | YES |
Turntable rotation speed: | 3-12 rpm adjustable |
Turntable diameter | 1650mm (Option: 1800mm, 2000mm,2200mm, 2400mm) |
Turntable height | 105mm (Include scale) |
Move the machine with forklift | Front & Rear |
Carriage Up/down Speed | Adjustable |
Power supply voltage | Customized |
1. Power pre-stretcch film carriage, save 30%-50% on packing cost.
2. Highly Reduce labor cost.
3. Lower investment（USD 2000-2500.）
4. Easy to installation.
5. Fast delivery.(3days)
Size of The Loads ( Pallets)
Min load size | 500mm (L) X 500mm (W) |
Max load size | 1200mm (L) X 1200mm (W) |
Max load height | 2400mm (Option:2800mm, 3000mm) |
Max load weight | 2000kg (4400lbs) |
Machine Performance
Packing efficiency | 20-30 loads/hour |
Load height sensing by PE | YES |
Turntable soft start & stop | YES |
Turntable rotation speed: | 3-12 rpm adjustable |
Turntable diameter | 1650mm (Option: 1800mm, 2000mm,2200mm, 2400mm) |
Turntable height | 105mm (Include scale) |
Move the machine with forklift | Front & Rear |
Carriage Up/down Speed | Adjustable |
Power supply voltage | Customized |
