Capacity: 1000L-5000L/H
Beer, containing yeast ≤ 30 million per milliliter,
After separation, the beer contains approximately ≤ 2 million yeast per milliliter.
Water flux | 5000L/h | |
Processing capacity | 1000-4000L/h | |
Maximum speed | 8500 rpm | |
Separation factor | ≥10000g | |
Effective working inner diameter of drum | 300mm | |
Equivalent settlement area | 22.5X107CM | |
Slag discharge method | Small valve slag discharge | |
Light liquid outlet pressure | ≤0.2MPa | |
Start mode | Frequency conversion start | |
Separator net weight | 614 kg | |
Overall dimensions (length x width x height) | 1120X850X1082mm | |
Motor | Power | 7.5 kW/50Hz/380V |
Water seal | Pressure | 0.2-0.3MPa |
Centrifugal oxygenation | ppb | ≤5 |
